CSC - AWP04-120W-40K-4P-UD
Manufacturer Code: AWP04-120W-40K-4P-UD
Not the right item? 💡 Contact Us
Image is for reference only. Actual product may vary.
Stock Availability
We may be able to find this product. Please contact us Monday to Friday, 8 AM to 4 PM, at (416) 493-2977 or click the button below.
Architectural Wall Pack LED 40K 120-347V
Attributes
| Kelvin | 4000 |
|---|---|
| Volts | 120-347 |
| Watts | Selectable 60, 80, 100 or 120W |
| UPC | 845599031192 |
| Lumens | 15960 |
| Colour Rendering Index (CRI) | 70 |
| Average Life in Hours | 50000 |
| Temperature Range | -40 to 45C (-40 to 113F) |
| Manufacturer Description | Power Selectable | 4000K | 120-347V | 15960 lm |
| Body Colour | BZ – Bronze |
| Manufacturer Name | CSC |
| Manufacturer Code | AWP04-120W-40K-4P-UD |
| Dimmable | 0-10V |
| Power Factor | 90 |
| IP Rating | IP65 |
| Item Weight (lbs) | 7.8 (3.55) |
Manufacturer Attributes
| Amperage | 1.6 a |
|---|---|
| Amperage | 1.6 a |
| Colortemperature | 4000k |
| Colortemperature | 4000k |
| Cri | 70 |
| Cri | 70 |
| Dimmable | 0-10v |
| Dimmable | 0-10v |
| Efficacy | 133 lm/w |
| Efficacy | 133 lm/w |
| Finish | Polyester powder coat |
| Finish | Polyester powder coat |
| Finishcolor | Bronze |
| Finishcolor | Bronze |
| Housing | Die-cast aluminum |
| Housing | Die-cast aluminum |
| Initiallumens | 15960 |
| Initiallumens | 15960 |
| Iprating | Ip65 |
| Iprating | Ip65 |
| Lifel70 | 50,000 hrs |
| Lifel70 | 50,000 hrs |
| Operatingtemperature | -40c to 45c |
| Operatingtemperature | -40c to 45c |
| Powerfactor | 0.9 |
| Powerfactor | 0.9 |
| Productdescription | 60w/80w/100w/120w | 4000k | 120-347v | 9005-15960 lm |
| Productdescription | Power selectable | 4000k | 120-347v | 15960 lm |
| Productid | 1079 |
| Productnumber | Awp04-120w-40k-4p-ud |
| Productnumber | Awp04-120w-40k-4p-ud |
| Unitgrossweight | 7.8 lbs |
| Unitgrossweight | 7.8 lbs |
| Upc | 845599031192 |
| Upc | 845599031192 |
| Voltage | 120-347v |
| Voltage | 120-347v |
| Watts | 60w/80w/100w/120w |
| Watts | 60w/80w/100w/120w |
| Websitedescription | Awp04 architectural wall pack, wall packs, 60w/80w/100w/120w, 4000k, 120-347v, bronze, dlc premium s-3b2g6o, 10 year warranty |
| Websitedescription | Awp04 architectural wall pack, wall packs, 60w/80w/100w/120w, 4000k, 120-347v, bronze, dlc premium s-3b2g6o, 10 year warranty |
